中空玻璃的密封质量，直接决定了其隔热、隔音性能和使用寿命。在过去，玻璃合片后的封胶工序长期依赖人工——不仅效率低、劳动强度大，涂胶质量还因人而异。全自动封胶线的出现，用人机界面+伺服控制+自动修角的完整解决方案，将这道工序推向了“一键操作、批量交付”的工业化新阶段。

王中王The sealing quality of insulating glass directly determines its thermal insulation, sound insulation performance, and service life. In the past, the sealing process after glass lamination relied on manual labor for a long time - not only was it inefficient and labor-intensive, but the quality of the coating also varied from person to person. The emergence of fully automatic sealing lines, with a complete solution of human-machine interface, servo control, and automatic corner trimming, has pushed this process to a new stage of industrialization with "one click operation and batch delivery".

王中王一、使用范围：面向规模化生产

1、 Scope of use: Targeting large-scale production

全自动封胶线适用于合片后的中空玻璃周边自动涂胶，是大规模玻璃深加工企业的标配设备。其可加工玻璃非常大尺寸覆盖2500×4000mm，非常小尺寸300×300mm，玻璃厚度范围12-56mm，打胶速度达5-40m/min。

The fully automatic sealing line is suitable for automatic coating around the hollow glass after lamination, and is a standard equipment for large-scale glass deep processing enterprises. It can process glass with a maximum size coverage of 2500 × 4000mm, a minimum size of 300 × 300mm, a glass thickness range of 12-56mm, and a glue application speed of 5-40m/min.

该设备支持双组份密封胶的自动供胶和切换，可配备两套供胶系统，在聚硫胶和硅酮胶之间一键切换。除了标准双玻中空玻璃，还支持三玻两腔、四玻三腔等复杂结构的自动涂胶。

This device supports automatic supply and switching of two-component sealant, and can be equipped with two sets of glue supply systems to switch between polysulfide glue and silicone glue with one click. In addition to standard double glass insulated glass, it also supports automatic gluing of complex structures such as three glass two cavity and four glass three cavity.

二、核心优势：质量、效率与操作的多维度升级

王中王2、 Core advantage: Comprehensive upgrade of quality, efficiency, and operation

全自动封胶线非常直观的优势体现在打胶质量的标准化上。设备涂胶后玻璃周边饱满无气线，角部充实，表面平整圆滑，无需人工修角。针对角部处理，部分机型在操作屏上一键开启修角功能，四个角可单独控制修角次数，配备自动上水修角棉，进一步提升角部美观度。

The most intuitive advantage of fully automatic sealing line lies in the standardization of adhesive quality. After the equipment is coated with glue, the edges of the glass are full and free of air lines, the corners are full, the surface is smooth and even, and there is no need for manual corner repair. For corner treatment, some models enable the corner trimming function with one click on the operation screen, and the four corners can be individually controlled for the number of corner trimming times. Equipped with automatic water filling corner trimming cotton, it further enhances the beauty of the corners.

王中王在效率层面，伺服控制系统采用国际品牌（如安川），性能稳定，定位合理。同步带式传送使玻璃输送平稳，第三段可预存玻璃，实现了流水作业和在线封胶的连续化生产。

In terms of efficiency, the servo control system adopts international brands (such as Yaskawa), with stable performance and precise positioning. The synchronous belt conveyor ensures smooth glass transportation, and the third section can pre store glass, achieving continuous production of assembly line operation and online sealing.

王中王柔性适应能力是新一代封胶线的突出亮点。面对市场越来越多的大小片（不等片）玻璃需求，通过技术升级和结构改造，设备可完成大小片的涂胶——机头后置适合镀膜玻璃（小片在内），机头前置适合常规玻璃（小片在外），每个边的参数均可独立输入操作界面。通过增加模块单元，还能实现自动上下片和异形玻璃涂胶。

王中王Flexible adaptability is a prominent feature of the new generation of sealing lines. Faced with the increasing demand for glass of different sizes in the market, through technological upgrades and structural modifications, the equipment can complete the gluing of large and small pieces - the rear of the machine head is suitable for coated glass (small pieces inside), and the front of the machine head is suitable for conventional glass (small pieces outside), and the parameters of each side can be independently input into the operation interface. By adding module units, automatic loading and unloading of sheets and adhesive coating of irregular glass can also be achieved.
